Phehlukwayo Metal is a top manufacturer and supplier located in Cape Town, South Africa. The company focuses on high-quality Incoloy 800HT Forgings that can operate in extreme conditions. Known for its precision engineering and reliability, Phehlukwayo Metal provides forgings that meet international standards for strength, durability, and resistance to corrosion. The Incoloy 800HT grade excels in high-temperature and high-stress situations, making it suitable for tough industrial uses. Each forging goes through strict quality control, ensuring customers receive reliable solutions for important engineering and process needs.
Phehlukwayo Metal’s Incoloy 800HT Forgings are commonly used in heat-treating equipment, chemical processing, power generation, and furnace parts. They work well in heat exchanger tubes, pressure vessels, reformer outlet manifolds, and superheater tubing because they resist high-temperature oxidation and corrosion. In the petrochemical and refinery sectors, these forgings perform well in processes with carburizing and nitriding atmospheres. Their exceptional strength and stability make them suitable for steam generators, piping systems, and other vital high-temperature assemblies, ensuring reliability and performance in harsh service settings.
Specifications ASTM B564 / ASME SB564, AMS 5766
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
| Alloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .25-.60 | .85-1.20 | .06-.10 max | 1.5 max | .015 max | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | Psi – 30,000 , MPa – 205 | 30 – 35 % |
| Density | 0.287 lb/in3 / 7.94 g/cm3 |
| Melting Point | 2475 – 2525 °F/ 1357 – 1385 °C |
| Specific Heat @ 70°F | 0.11 Btu/lb•°F |
| Permeability @ 70°F Annealed | 1.014 (200 Oersted) |
| Curie Temperature | -115 °C/ -175 °F |
| Elastic Modulus | 28.50 X 106 psi |
| Electrical Resistivity @ 70°F | 595 ohm•circ mil/ft |
| Annealling Incoloy 800 | 983 – 1038 °C / 1800 – 1900 °F |
| Annealling Incoloy 800H / Ht | 1147 – 1177°C / 2100 – 2150 °F |
| Quench | Rapid Air / Water |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 800HT | N08811 | 1.4959 | – | X8NiCrAlTi32-21 | NCF 800HT | NA 15(HT) | ЭИ670 | XH32T |
To determine if Incoloy 800HT Forgings meet your specific needs, assess their high-temperature resistance, oxidation, and carburization properties against your application requirements. Consulting with a supplier for detailed material specifications and testing options can also ensure compatibility.
The ideal temperature range for forging Incoloy 800HT is between 2100°F (1149°C) and 2300°F (1260°C). This range ensures optimal workability, mechanical properties, and maintains the material's strength and resistance to oxidation.
Temperature control is crucial for maintaining the desired mechanical properties of forged Incoloy 800HT, as overheating or insufficient heating can lead to reduced strength and ductility. Proper temperature management ensures optimal grain structure, resistance to oxidation, and overall performance in high-temperature applications.
Incoloy 800HT Forgings are widely used in high-temperature applications such as furnace components, heat exchangers and reactor cores.These are excellent for the gas turbines, power plants and petrochemical industries where the oxidation, carburization and thermal fatigue resistances are extremely important. The forgings find application in other equipment such as combustion chambers, superheaters and heat treatment equipment where they offer high strength and creep resistance at elevated temperatures for reliable service. Their ability to withstand hostile environments makes them ideal for severe applications where a long service life is desired.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
