Phehlukwayo Metal, located in Cape Town, South Africa, is a reputable manufacturer and supplier that specializes in high-performance alloys, particularly Incoloy 925 Forgings. Known for their precision engineering and unwavering quality, this company caters to a variety of industries that demand exceptional corrosion resistance and mechanical strength. Their Incoloy 925 Forgings are meticulously crafted to adhere to strict international standards, guaranteeing reliability even in the toughest environments. With a strong emphasis on durability, performance, and customer satisfaction, Phehlukwayo Metal delivers solutions that are essential for critical applications across marine, chemical, and energy sectors, making them a go-to partner for businesses in search of top-notch advanced alloy products.
Incoloy 925 Forgings are primarily made up of nickel, iron, and chromium, with added molybdenum, copper, and trace amounts of titanium and aluminum to boost corrosion resistance and strength. This alloy is particularly known for its outstanding resistance to stress corrosion cracking, pitting, and crevice corrosion, especially in environments rich in chlorides and acids. On the mechanical side, Incoloy 925 Forgings provide high tensile and yield strength, excellent fatigue resistance, and stable performance even at elevated temperatures. Its unique blend of toughness and corrosion resistance makes it perfect for long-term use in harsh chemical and marine conditions, ensuring structural integrity under demanding operational stresses.
Specifications ASTM B637 / ASME SB637
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | Ni% | Cr% | Fe% | Mo% | Cu% | Ti% | Al% | Mn% | Si% | Nb% | C% | S% |
| Incoloy 925 | 42.0-46.0 | 19.5-22.5 | Min 22 | 2.5-3.5 | 1.5-3.0 | 1.9-2.4 | 0.1-0.5 | Max 1.0 | Max 0.5 | Max 0.5 | Max 0.03 | Max 0.03 |
| UNS | Heat Treatment | Tensile Strength, min, psi (MPa) | Yield Strength (0.2 % offset), min, psi (MPa) | Elongation in 2 in. (50 mm) or 4D, min, % | Reduction of Area, min, % | Brinell or (Rockwell C) Hardness |
| ASTM B637 UNS N09925 | solution + precipitation harden | 140 000 (965) | 105 000 (724) / 110 000 (758) | 18 | 25 | 346 max (38, Rc max) |
| STANDARD | UNS | WNR. |
| Alloy 925 | N09925 | – |
The ideal temperature range for forging Incoloy 925 is between 1,800°F (982°C) and 2,200°F (1,204°C). Forging should be done within this range to achieve optimal material properties and avoid overheating.
Incoloy 925 forgings require minimal maintenance due to their excellent corrosion resistance. Regular inspection for signs of wear, cracks, or environmental damage is recommended to ensure long-term performance.
Incoloy 925 forgings have limited high-temperature strength beyond 1,600°F (871°C) and may suffer from reduced ductility in extreme conditions. They also exhibit moderate resistance to pitting and crevice corrosion in highly aggressive environments.
Incoloy 925 Forgings find extensive use in chemical processing, seawater handling, and the oil and gas industries, where resistance to chlorides, acids, and other corrosive substances is crucial. They are particularly well-suited for valves, pumps, heat exchangers, and piping systems that face harsh environments. This alloy is also utilized in marine equipment, desalination plants, and chemical reactors, offering reliable performance under high stress and corrosive conditions. Phehlukwayo Metal’s Incoloy 925 Forgings are highly regarded for their dependability in safety-critical components, ensuring that they meet the rigorous demands of various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
