Phehlukwayo Metal, based in Cape Town, South Africa, is a reliable manufacturer and supplier of top-notch nickel-based alloys, including Nimonic 115 Bars and Rods. These products are crafted for outstanding performance in high-temperature settings, boasting remarkable strength, resistance to oxidation, and excellent creep properties. Phehlukwayo Metal is committed to delivering precision-engineered products that adhere to strict international standards. Nimonic 115 Bars and Rods are perfect for demanding industrial applications where reliability and performance are crucial, especially in fields like aerospace, power generation, and high-stress engineering environments that operate under extreme thermal and mechanical conditions.
The composition of Nimonic 115 Bars and Rods primarily includes nickel, along with 14–16% chromium, 3–5% cobalt, 4–5% aluminum, and trace amounts of titanium and molybdenum to boost strength and thermal stability. These elements work together to provide exceptional resistance to oxidation, corrosion, and thermal fatigue. On the mechanical side, Nimonic 115 showcases high tensile and yield strength, impressive creep and rupture resistance, and stability at temperatures reaching up to 1050°C. The alloy’s blend of toughness, durability, and heat resistance makes it a go-to choice for high-performance applications that demand long-term reliability.
| Grade | Nimonic 115 – UNS |
|---|---|
| Standard | ASTM, ASME, API, GB, AISI, DIN, EN, SUS, UNS |
| Nimonic 115 Round bar size | Diameter: 3mm~800mm |
| Nimonic 115 Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Nimonic 115 Square bar size | 4mm*4mm~100mm*100mm |
| Nimonic 115 Flat bar size | Thickness: 2mm~100mm |
| Width: 10mm~500mm | |
| Nimonic 115 Hex Bar size | 2mm~100mm |
| Nimonic 115 Billet Size | 1/2″ to 495mm Diameter |
| Nimonic 115 Rectangles Size | 33mm x 30mm to 295mm x 1066mm |
| LENGTHS | 12 RANDOM LENGTHS AND LONG BARS:15 20 RANDOM LENGTHS |
| Nimonic 115 Round Bar Standard Dimensions | Diameter / Height:As the customer required |
| Finish | Bright, Polish, Bright, Rough Turned, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Condition | Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished, Annealed round bar |
| Technique | Nimonic 115 Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod |
| Form | Round, Rod, Precision Ground Bar, Square, Round Rod, Hollow, Hex (A/F), Triangle, Rectangle, Threaded, T-Bar, Half Round Bar, Flat Bar, Rings, Blocks, Billet, Ingot, I/H Bar, Angle, Channel Bar, Profiles, Forging Etc. |
| Element | Content (%) |
|---|---|
| Nickel, Ni | 54 |
| Chromium, Cr | 14.0-16.0 |
| Cobalt, Co | 13.0-15.5 |
| Aluminum, Al | 4.50-5.50 |
| Molybdenum, Mo | 3.0-5.0 |
| Titanium, Ti | 3.50-4.50 |
| Iron, Fe | 1.0 |
| Manganese, Mn | 1.0 |
| Silicon, Si | 1.0 |
| Copper, Cu | 0.20 |
| Zirconium, Zr | 0.15 |
| Carbon, C | 0.12-0.20 |
| Sulfur, S | 0.015 |
| Boron, B | 0.010-0.025 |
| Tensile Strength | Min 185KSI | Min 1277MPA |
| Yield Strength | Min 141KSI | MIN 973MPA |
| Elongation | Min 38% |
| Alloy Name | Trade Name | UNS No. | British Specs | American Specs | German Specs | French Specs |
|---|---|---|---|---|---|---|
| Alloy 115 | Nimonic 115 | BS HR4 | WS 2.4636 | AFNOR NCK 15ATD |
Nimonic 115 rods are available in sizes ranging from 1/8" to 4" diameter. Finishes include cold drawn, polished, and rough turned, suitable for high-temperature applications.
Nimonic 115 rods typically come in standard sizes ranging from 1/8" to 6" in diameter, with lengths varying from 3' to 20' depending on the manufacturer and customer specifications.
Yes, Nimonic 115 rods can be supplied in both polished and matte finishes, depending on the specific requirements and customer preferences. These finishes are available from various suppliers.
Nimonic 115 Bars and Rods are extensively used in the aerospace sector for turbine blades, combustion chambers, and afterburner components, where extreme heat and stress are the norm. They also play a vital role in power generation systems, gas turbines, and high-performance engines, thanks to their excellent thermal and mechanical stability. Furthermore, these bars and rods are essential in chemical processing and industrial furnaces, where resistance to oxidation and corrosion is critical. With Phehlukwayo Metal’s Nimonic 115 Bars and Rods, you can count on unmatched reliability, making them a trusted choice for high-temperature and high-pressure engineering applications around the globe.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
