Phehlukwayo Metal, based in Cape Town, South Africa, is a reputable manufacturer and supplier of top-notch stainless steel products, including Nitronic 60 Bars and Rods. These bars and rods are celebrated for their remarkable wear resistance, strength, and ability to withstand corrosion, all while adhering to strict industrial standards. With a blend of advanced metallurgical knowledge and precise manufacturing techniques, Phehlukwayo Metal delivers durable and dependable components for even the most demanding applications. Nitronic 60 Bars and Rods are especially prized for their resistance to galling, pitting, and abrasion, making them a perfect fit for industries like chemical processing, marine engineering, and heavy machinery.
The composition of Nitronic 60 Bars and Rods primarily includes iron, along with 19–21% chromium, 8–10% nickel, 2–3% manganese, and trace amounts of nitrogen, copper, and molybdenum to boost corrosion resistance and mechanical performance. This alloy showcases impressive tensile and yield strength, excellent wear and galling resistance, and remarkable toughness. It maintains its shape under stress and performs reliably in high-load situations. Additionally, Nitronic 60 is highly resistant to both oxidizing and reducing environments, making it ideal for critical components that require durability, low maintenance, and a long service life.
| Grade | Nitronic Alloy 60 (UNS No. S21800) Round Bar |
|---|---|
| Specification | DIN, JIS, ASTM, BS, ASME, AISI |
| Nitronic 60 Square bar size | 4 to 100mm |
| Nitronic Alloy 60 Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Nitronic UNS S21800 Hex Bar size | 2-100mm A/F |
| Nitronic 60 Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Nitronic Alloy 60 Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Nitronic UNS S21800 Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Nitronic 60 Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Nitronic UNS S21800 Round bar size | Diameter: 3-~800mm |
| Nitronic 60 Billet Size | 1/2″ to 495mm Diameter |
| Nitronic 60 Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Nitronic Alloy 60 Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Nitronic UNS S21800 Technique | Nitronic 60 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Nitronic 60 Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Form | Nitronic 60 Round, Rod, T-Bar, Nickel Alloy Channel Bar, Precision Ground Bar, Nickel Alloy Flat Bar, Nickel Alloy Square Bar, Nickel Alloy Blocks, Nickel Alloy Round Rod, Nickel Alloy Rings, Nickel Alloy Hollow, Nickel Alloy Triangle, Rectangle, Hex (A/F), Nickel Alloy Threaded, Half Round Bar, Profiles, Nickel Alloy Billet, Nickel Alloy Ingot, I/H Bar, Forging etc. |
| Processing | Bar cutting to 650mm |
| Our Nitronic 60 Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | S | Si | N | Ni | Cr |
| Nitronic Alloy 60 | 0.10 | 7.0 – 9.0 | 0.030 | 3.5 – 4.5 | 0.08 – 0.18 | 8.0 – 9.0 | 16.0 – 18.0 |
| Ultimate Tensile Strength, ksi | 95 |
| 0.2% Yield Strength, ksi | 50 |
| Elongation, % | 35 |
| Reduction of Area, % | 55 |
| Hardness MAX, Brinell | 241 |
| STANDARD | UNS | DIN |
|---|---|---|
| Nitronic 60 Round Bars | S21800 | – |
Common finishes for Nitronic 60 Bar include mill finish, pickled and passivated, polished, brushed, and cold drawn. These finishes provide varying levels of smoothness, corrosion resistance, and aesthetic appeal.
The most common diameters for Nitronic XM 19 rod range from 0.125 inches (1/8") to 12 inches, with popular sizes including 1/4", 1/2", 1", 2", and 3".
Nitronic XM 19 rods typically come in standard sizes ranging from 1/8" to 3" in diameter, with lengths from 12" to 144". Custom sizes may also be available.
Nitronic 60 Bars and Rods are extensively utilized in industries where resistance to galling, wear, and corrosion is crucial. They are perfect for applications like valve stems, pump shafts, fasteners, bearings, and other mechanical components that experience sliding or rotational contact. Furthermore, they are used in chemical processing equipment, marine hardware, and industrial machinery that demands high-performance materials. Phehlukwayo Metal is committed to ensuring that their Nitronic 60 Bars and Rods meet stringent quality standards, providing robust, long-lasting solutions for engineering, marine, and heavy-duty industrial applications that require exceptional reliability and resistance to harsh conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
