Phehlukwayo Metal stands out as a premier manufacturer and supplier located in Cape Town, South Africa. They specialize in high-quality Stainless Steel 17-7 PH Hex Bars and Rods, catering to a diverse array of industrial and engineering needs. Known for their precision engineering and cutting-edge manufacturing techniques, the company is committed to upholding global standards, ensuring that every product they offer delivers remarkable performance and reliability. The Stainless Steel 17-7 PH Hex Bars and Rods from Phehlukwayo Metal are highly regarded for their exceptional strength, resistance to corrosion, and impressive hardness, making them perfect for demanding environments that experience high stress and temperatures across various industries.
The Stainless Steel 17-7 PH Hex Bar/Rod is a precipitation-hardening stainless steel alloy, primarily made up of iron, 17% chromium, 7% nickel, along with trace amounts of aluminum. This unique blend results in a fantastic mix of strength, ductility, and corrosion resistance. After undergoing heat treatment, the alloy can achieve tensile strength levels of up to 1250 MPa and yield strength around 1070 MPa, along with excellent resistance to fatigue and creep. It also maintains solid mechanical stability at temperatures reaching up to 600°F (315°C) and boasts great forming and welding characteristics when in its annealed state.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-7 PH | .09 | – | 16.0 – 18.0 | – | Bal | 1.0 | 6.50 – 7.75 | .04 | 0.04 | 1.0 max |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 17-7 PH | 170000 psi | 140000 psi | 6% | 38 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-7 PH | – | S17700 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Common challenges with Stainless Steel 17-7 PH Hex Bar include difficulty in machining due to its hardness, sensitivity to stress corrosion cracking, and the need for precise heat treatment to achieve optimal properties.
Stainless Steel 17-4 PH Hex Bar and Rod should be stored in a dry, clean environment, away from moisture and corrosive substances. Ensure proper ventilation and avoid direct contact with chemicals or humidity.
Yes, Stainless Steel 17-7 PH Hex Bar and Rod are fully recyclable. Stainless steel can be melted down and reused, making it an environmentally friendly material for sustainable manufacturing processes.
Stainless Steel 17-7 PH Hex Bars and Rods find extensive applications in the aerospace, marine, chemical processing, and petrochemical sectors. They are particularly well-suited for creating fasteners, springs, shafts, valves, and precision components that require high strength and corrosion resistance. Additionally, these hex bars and rods are utilized in power generation, defense, and automotive industries, where maintaining dimensional stability and mechanical reliability is crucial. Their hexagonal shape not only enhances grip but also improves machinability, making them a top choice for both structural and mechanical components in tough service conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
