Phehlukwayo Metal, located in the vibrant city of Cape Town, South Africa, stands out as a top-notch manufacturer and supplier of premium stainless steel products, with a particular focus on Stainless Steel 416 Square Bars and Rods. Known for their precision engineering, exceptional durability, and unwavering quality, this company meets a wide range of industrial demands. By blending cutting-edge manufacturing techniques with strict quality control, Phehlukwayo Metal ensures that their products comply with both local and international standards. Their Stainless Steel 416 Square Bars and Rods are celebrated for their reliability, resistance to corrosion, and ease of machining, making them a go-to choice for businesses that prioritize performance and longevity in their metal components.
Stainless Steel 416 is a martensitic stainless steel alloy characterized by a high carbon content, with added sulfur to enhance machinability. Typically, it contains about 0.15–0.20% carbon, 12–14% chromium, 1% manganese, and 0.15% sulfur. In terms of mechanical properties, it boasts impressive tensile strength of around 655 MPa and a yield strength of roughly 345 MPa, along with a moderate hardness rating of 180–220 HB. This alloy can be heat-treated, which boosts its hardness and wear resistance while still maintaining good corrosion resistance in mildly corrosive environments. Its blend of machinability, strength, and durability makes it perfect for precision components.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 410 | 0.15 | 11.5-13.5 | 1.00 | 0.75 | 0.040 | 0.030 | 1.00 |
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50 mm) | Hardness Brinell (HB) | Impact Charpy V (J) |
|---|---|---|---|---|---|
| Annealed * | 480 min | 275 min | 16 min | – | – |
| 204 | 1475 | 1005 | 11 | 400 | 30 |
| 316 | 1470 | 961 | 18 | 400 | 36 |
| 427 | 1340 | 920 | 18.5 | 405 | # |
| 538 | 985 | 730 | 16 | 321 | # |
| 593 | 870 | 675 | 20 | 255 | 39 |
| 650 | 300 | 270 | 29.5 | 225 | 80 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 410 | 1.4006 | S41000 | SUS 410 | 410S21 | – | – | 56A |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 410 square bars can be welded, but preheating and post-weld heat treatment are often recommended to avoid cracking. Proper welding techniques ensure strong, durable joints.
To ensure the quality of Stainless Steel 410 square bars, source them from reputable suppliers and conduct material testing, such as tensile strength and hardness tests. Additionally, check for proper surface finish and dimensional accuracy.
Yes, we provide 410 Stainless Steel Square Bars and Rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@phehlukwayometal.co.za
Stainless Steel 416 Square Bars and Rods find extensive use in applications where high machinability and moderate corrosion resistance are crucial. They are particularly suited for shafts, gears, screws, valve parts, and automotive components that require precision engineering. Industries such as manufacturing, automotive, and machinery depend on 416 bars to create durable, high-performance parts. Moreover, they are also utilized in the production of fasteners, fittings, and small mechanical parts that require both strength and a smooth surface finish. Their versatility, coupled with ease of machining, makes Stainless Steel 416 an excellent choice for a variety of applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phehlukwayo Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Cape Town, South Africa
