Phehlukwayo Metal, located in Cape Town, South Africa, stands out as a top-notch manufacturer and supplier of high-quality Titanium Gr 11 Forgings. These forgings are prized for their remarkable corrosion resistance, durability, and strength, making them perfect for even the toughest industrial settings. Phehlukwayo Metal is committed to precision engineering and upholding international quality standards in every product they create. With a keen focus on performance and reliability, the company provides Titanium Gr 11 Forgings that are ideal for use in chemical processing, marine, aerospace, and power generation industries, where resistance to harsh environments is a must.
The Titanium Gr 11 Forgings are mainly made of titanium, with a small amount of palladium (about 0.12–0.25%) added to boost corrosion resistance. This alloy is known for its excellent resistance to reducing acids, great weldability, and impressive mechanical strength. Typically, it boasts a tensile strength ranging from 345–450 MPa and outstanding ductility. The blend of low density, high toughness, and exceptional resistance to crevice and pitting corrosion makes Titanium Gr 11 a versatile option for challenging operational conditions.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Yes, Titanium Gr 11 forgings are highly corrosion-resistant, especially to oxidizing environments and seawater. This makes them ideal for applications in industries like aerospace, marine, and chemical processing, ensuring long-lasting durability.
Titanium Gr 11 forgings are commonly used in industries such as aerospace, marine, chemical processing, medical, and power generation. Their strength, corrosion resistance, and high-performance capabilities make them ideal for demanding applications.
Yes, Titanium Gr 11 forgings can be customized for specific applications, offering tailored sizes, shapes, and properties to meet unique industry requirements, ensuring optimal performance and reliability in demanding environments.
You’ll find Titanium Gr 11 Forgings widely used in chemical processing plants, marine environments, power generation systems, and desalination equipment. Their superior corrosion resistance against chlorides and acids makes them perfect for heat exchangers, pressure vessels, piping systems, and evaporator coils. They’re also utilized in aerospace components and offshore structures where strength and durability are essential. Phehlukwayo Metal’s Titanium Gr 11 Forgings deliver unmatched performance, longevity, and reliability in applications that demand high resistance to corrosion and mechanical stress.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Phehlukwayo Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Cape Town, South Africa
