Phehlukwayo Metal, based in Cape Town, South Africa, has built a solid reputation as a top-notch manufacturer and supplier of high-quality Titanium Gr 7 Forgings. These forgings are celebrated for their remarkable corrosion resistance, particularly in both oxidizing and reducing environments, making them perfect for critical industrial applications. Phehlukwayo Metal is committed to delivering precise engineering, durability, and consistency in every product, ensuring they meet global quality standards. With cutting-edge production techniques and a strong focus on performance, the company provides Titanium Gr 7 Forgings that industries like chemical processing, marine engineering, and power generation can rely on for their durability and longevity.
Titanium Gr 7 Forgings are primarily made of titanium, with a small addition of palladium (around 0.12–0.25%) to boost corrosion resistance. This alloy boasts an impressive strength-to-weight ratio, excellent weldability, and strong resistance to crevice and pitting corrosion. On the mechanical side, Titanium Gr 7 shows tensile strength ranging from 345–450 MPa and outstanding ductility, making it well-suited for challenging environments. Its thermal stability and resistance to acidic and chloride-rich media make it a go-to choice for critical industrial operations.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 7 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | .12 – .25 |
| 0.2% Proof Stress MPa | Tensile Strength MPa | Elongation % |
| 275-475 | 345 | 20 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 7 | 3.7235 | R52400 |
Yes, Titanium Grade 7 (Ti-0.2Pd) is highly corrosion-resistant, especially in harsh environments like seawater and acidic conditions, due to the addition of palladium, enhancing its ability to resist corrosion.
Titanium Grade 7 forgings are commonly used in industries like aerospace, chemical processing, marine, medical, and power generation due to their exceptional corrosion resistance, strength, and biocompatibility in challenging environments.
Titanium Grade 7 forgings are available in various sizes and shapes, including bars, billets, rings, discs, and custom configurations, typically ranging from small to large diameters for different industrial applications.
These Titanium Gr 7 Forgings find extensive use in chemical processing, desalination plants, power generation, and marine applications. Their exceptional resistance to acids like hydrochloric and sulfuric acid makes them ideal for heat exchangers, reactor vessels, and condenser tubing. In offshore and marine settings, they provide long-lasting durability against seawater corrosion. Additionally, they are utilized in the production of anodes, piping systems, and pressure vessels. With Phehlukwayo Metal’s Titanium Gr 7 Forgings, you can count on high performance, reliability, and an extended service life even in the harshest environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
